Position Meaning
7 Hyphen –
8 … 11 Detection height 0000 = Special detection height
see t
able 4, page 11
12 Interfaces, I/O see table 5, page 11
13 Options 1 = none
14 and 15 Optical properties see table 6, page 12
16 and 17 Preconfiguration of the I/O con‐
nect
ions and the software
see "MLG-2 Prime preconfigura‐
tions", page 12
3.2.1 MLG-2 Prime monitoring height
Table 4: MLG-2 Prime (mm) monitoring height
Type
MLG05… MLG10… MLG20... MLG25… MLG30... MLG50…
Monitoring height
[mm]
145 140 140 – – –
295 290 280 275 270 250
445 440 440 425 420 400
595 590 580 575 570 550
745 740 740 725 720 700
895 890 880 875 870 850
1045 1040 1040 1025 1020 1000
1195 1190 1180 1175 1170 1150
1345 1340 1340 1325 1320 1300
1495 1490 1480 1475 1470 1450
1645 1640 1640 1625 1620 1600
1795 1790 1780 1775 1770 1750
1945 1940 1940 1925 1920 1900
2095 2090 2080 2075 2070 2050
2245 2240 2240 2225 2220 2200
2395 2390 2380 2375 2370 2350
2545 2540 2540 2525 2520 2500
– 2690 2680 2675 2670 2650
– 2840 2840 2825 2820 2800
– 2990 2980 2975 2970 2950
– 3140 3140 3125 3120 3100
3.2.2 Combinations of MLG-2 Prime inputs and outputs
Table 5: Possible combinations of MLG-2 Prime inputs and outputs
Position 12 Inputs and outputs, data interface Connection type
A 1 × switching output (Q) and
2 × analog out
put (QA)
M12/5-pin, A-coded
D 3 × switching output (Q)
or
1 × in
put (IN) and
2 × s
witching output (Q)
M12/5-pin, A-coded
PRODUCT DESCRIPTION 3
8018715.16YM / 2020-02-13 | SICK O P E R A T I N G I N S T R U C T I O N S | MLG-2 Prime
11
Subject to change without notice
