Selecting output mode and setting parameters
> Q1 output > > Q1 mode > > Q1 Alarm >
> Q1 Output > > Parameter > > Select option >
Parameter Value Factory settings
Q1 Switch point logic High-active
Low-active
High-active
7.4.3.6 Q1 Signal level warning menu
If the signal level falls below a threshold, a warning is issued via digital outputs Q1
and Q2. The signal threshold can be taught-in or set manually as a numerical value.
The signal level is a sensor-specific, unitless value. Adjusting the signal level using
application-specific test measurements is recommended.
Selecting output mode and setting parameters
> Q1 output > > Q1 mode > > Q1 Signal level warning >
> Q1 Output > > Parameter > > Select option, teach-in or set value >
Parameter Value Factory settings
Q1 Signal threshold (auto) Setting the switching point
0 ... 5,000
1700
Q1 Signal threshold (manual)
Q1 Switch point logic High-active
Low-active
High-active
Q1 Timer mode Off
Switch-on delay
Switch-off delay
Switch-on/off delay
Impulse (one shot)
Off
Q1 Timer setup 1ms ... 30,000ms 1ms
7.4.3.7 Q1 Edge height jump menu
If a measured value jump occurs between two measured values, a signal is output. A
typical application is copy or scale counting in print applications. The device takes on
the complex evaluation tasks carried out by the control system.
Settings for using the function
•
Q1 Min./Max. menu Height jump
•
Fixed Cycle time menu (recommended)
NOTE
In Auto mode, fluctuating remission values of the object surface can change the
cycle time of the device. This means that reliable detection is not guaranteed at
high detection speeds or with small structures.
•
Average filter off (recommended)
•
Q1/Q2 Hysteresis menu (if required)
•
Q1 Jump direction menu (if required)
•
Q1 Cycle offset menu (if required)
Selecting output mode and setting parameters
> Q1 output > > Q1 mode > > Q1 Edge height jump >
