3UG4.1 line monitoring relay
6.3 3UG4512 line monitoring relay
3UG4 / 3RR2 monitoring relays
Manual, 05/2016, NEB927043002000/RS-AC/004
119
Mechanical design
3UG4512-1A...
3UG4512-1B...
3UG4512-2A...
3UG4512-2B...
Width
mm
22.5
Height
mm
83
92
84
94
Depth
mm
91
Built in orientation
any
Distance, to be
maintained, to earthed
part
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be
maintained, to the ranks
assembly
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Distance, to be
maintained, conductive
elements
• forwards
mm
0
• backwards
mm
0
• sidewards
mm
0
• upwards
mm
0
• downwards
mm
0
Type of mounting
snap-on mounting
Product function
removable
terminal for auxiliary and
control circuit
Yes
