3UG4625 residual current monitoring relay with 3UL23 transformer
8.7 Technical data
3UG4 / 3RR2 monitoring relays
Manual, 05/2016, NEB927043002000/RS-AC/004
209
3UG4625-.....
Type of voltage of the controlled supply voltage
AC/DC
Control supply voltage
• at 50 Hz at AC
– rated value
V
24 … 240
• at 60 Hz at AC
– rated value
V
24 … 240
• for DC
– rated value
V
24 … 240
Working range factor supply voltage rated value
• at 50 Hz
– for AC
0.85 … 1.1
• at 60 Hz
– for AC
0.85 … 1.1
• for DC
0.85 … 1.1
Impulse voltage resistance rated value
kV
4
Recorded real power
W
2
Protection class IP
IP20
Electromagnetic compatibility
IEC 60947-1 / IEC 61000-6-2 /
IEC 61000-6-4
Operating current at 17 V minimum
mA
5
Continuous current
of the DIAZED fuse link of the
output relay
A 4
Resistance against vibration according to IEC 60068-2-6
1 ... 6 Hz: 15 mm, 6 ... 500 Hz: 2g
Resistance against shock
according to IEC 60068-2-27
sinusoidal half-wave 15g / 11 ms
Installation altitude at a height over sea level maximum
m
2 000
Current carrying capacity of output relay at AC-15
• at 250 V at 50/60 Hz
A
3
• at 400 V at 50/60 Hz
A
3
Current carrying capacity of output relay at DC-13
• at 24 V
A
1
• at 125 V
A
0.2
• at 250 V
A
0.1
Conductor-bound parasitic coupling BURST
according to
IEC 61000-4-4
2 kV
Conductor-bound parasitic coupling conductor-earth SURGE
according to IEC 61000-4-5
2 kV
Conductor-bound parasitic coupling conductor-conductor
SURGE according to IEC 61000-4-5
1 kV
