System overview
3.6 Menu-based operation
3UG4 / 3RR2 monitoring relays
42 Manual, 05/2016, NEB927043002000/RS-AC/004
Navigation in the menu
There are basically two ways of navigating on both menu levels:
● Brief pressing the SET key
(≤ 0.5 s)
You can jump from one parameter to the next within one menu level by briefly pressing
the SET key
. The order is not variable.
Entry Display at the RUN menu level Display at the SET menu level
1. Current measuring value (MeasValue1 /
MeasValue2 / ...) or error symbol (Error1 / Error2 /
Error3 / ...), switching contact symbols and
monitoring methods for diagnostics
Parameter1
2. Threshold1 Parameter2
3. Threshold2 Parameter3
4. Threshold3 ...
5. ...
Note
The setting options a device actually offers depends on the type and can be looked up in
the relevant chapters on operation in this manual.
You can find full details of menu-based operation for the individual devices in Appendix D
"Menu-based operation" (Page 389).
● Pressing and holding the SET key (> 2.5 s)
By pressing and holding the SET key
, the menu changes from RUN to SET and vice
versa.
– RUN → SET
Menu level change can be started from any display. While the SET key is pressed,
appears on the display.
After a successful change, you always arrive at the first menu item (parameter1) of the
"SET" menu level.
In the event of an error, changing to the "SET" menu level is only possible from "RUN-
VALUE"
②. If an error is indicated, the SET key must be pressed first briefly (< 0.5 s).
– SET → RUN
You can switch menus from any of the menu commands. While the SET key
is
pressed,
appears on the display.
After a successful change, you arrive at current measuring value (measuringvalue1) or
the current error of the RUN menu level.
