Line connection and line-side power components
3.9 Active Interface Modules internal air cooling
Booksize Power Units
132 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
M6 screws, Torx T30 (not hexagon-head screws)
Figure 3-62 Installation of 55 kW Active Interface Module
for all screws: 6 Nm
Table 3- 25 Protective conductor connection
80 / 120 kW Threaded hole M8 / 13 Nm
