Line connection and line-side power components
3.8 Line reactors
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
97
3.8.3.3
Technical data
Table 3- 15 Technical data for HFD line reactors
Unit
6SL3000–
0DE21-
6AAx
6SL3000–
0DE23-
6AAx
6SL3000–
0DE25-
5AAx
6SL3000–
0DE28-
0AAx
6SL3000-
0DE31-
2AAx
Power
kW
16
36
55
80
120
Rated current
A
rms
30
67
103
150
225
Power loss
1)
(see power
loss tables)
W 170 250 350 450 590
Weight
kg
9
21
27
37
67
Degree of protection
according to EN 60529
IP20 IP00 (no touch protection) IP00 (no touch protection)
Mounting position
Any
1)
Data for line operation
