3.9 Active Interface Modules internal air cooling
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
135
3.9.9
Technical data
Table 3- 27 Technical data
Active Interface Module
6SL3100-
0BE21-6ABx
0BE23-6ABx
0BE25-5ABx
0BE28-0ABx
0BE31-2ABx
16 kW
36 kW
55 kW
80 kW
120 kW
P
max
kW 35 70 110 131 175
I
rated
A
27
60
88
132
200
I
max
A
59
117
176
218
292
Current requirement of
the
24 VDC electronics
power supply
A 0,25 0,49 0,6 1,2 1,2
Line voltage
V
3-phase 380°V°...°480°VAC ±°10%
Line frequency
Hz
47 … 63
Cooling air requirement
m
3
/h
112
160
300
600
600
Power loss
1)
(see power
loss tables (Page 781))
W 270 340 380 490 585
Weight
kg
10,7
18,5
21
29
35,5
Connection cross-
section
mm
2
10 35 50 120 120
PE connecting studs
M5
M6
M6
M8
M8
1)
Referred to U
DC link
= 600 V
