System overview
2.5 System data
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
45
2.5
System data
Unless explicitly specified otherwise, the following technical data is valid for components of
the SINAMICS S120 booksize drive system.
Table 2- 1 Electrical data
Line connection voltage
3 AC 380 … 480 V ±10 % (-15 % < 1 min)
Line frequency
47 … 63 Hz
Electronics power supply 24 V DC -15/+20 %
1)
, Safety extra-low voltage (PELV or
SELV)
(see Chapter 24 V DC supply voltage (Page 719))
Short-circuit current rating SCCR according to UL508C
(up to 600 V)
• 1.1 … 447 kW: 65 kA
• 448 … 671 kW: 84 kA
• 672 … 1193 kW: 170 kA
• ≥ 1194 kW: 200 kA
Radio interference suppression acc. to EN 61800-3 Category C2 (optional)
for system versions conformant with documentation
Overvoltage category
III
Degree of contamination
2
1)
If a motor holding brake is used, restricted voltage tolerances (24 V ± 10 %) may have to be taken into account.
Table 2- 2 Modules
Line Modules in the booksize format
Max. permissible supply voltage
3 AC 480 V
Rated pulse frequency
(for Active Line Modules in booksize format only)
8 kHz
Motor Modules in the booksize format
DC link supply voltage 510 … 720 V DC
Rated pulse frequency 4 kHz
At higher pulse frequencies the corresponding characteristic
for current derating must be taken into consideration
