Siemens 6SL3120-2TE21-0AA3

Line Modules Booksize
4.5 Active Line Modules Liquid Cooled
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
227
Liquid Cooled
6SL3135-7TE31-2AA3
Rated power
kW
120
Max. ambient temperature
without derating
with derating
° C
° C
40
55
DC link capacitance
:
Active Line Module
Drive line-up, max.
μF
μF
3995
20000
Power factor
cosϕ
1
Circuit breaker
(IEC 60947 and UL) See Section Overcurrent protection using line fuses and
circuit breakers (Page 51)
Rated short-circuit current SCCR
3)
kA
65
Rated flow rate
for water
at 70 kPa pressure drop (for other coolants,
see Cooling circuit and coolant properties
(Page 795)
l/min 8
Volume of liquid internal
ml
100
Max. coolant temperature
without derating
with derating
° C
° C
45
50
Max. permissible heat sink temperature
° C
80
Weight
kg 23
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
Default for 400 V line systems; undervoltage trip threshold is adjusted to the parameterized rated voltage
3)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
