Siemens 6SL3120-2TE21-0AA3

Line Modules Booksize
4.7 Basic Line Modules with cold plate
Booksize Power Units
270 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
6SL3136-
1TE22-0AA0
1TE24-0AA0
1TE31-0AA0
Max. ambient temperature
without derating
with derating
° C
° C
40
55
40
55
40
55
Max. permissible heat sink temperature
° C
70
70
70
Weight
kg
6,4
10,9
16,4
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
Default for 400 V line systems; undervoltage trip threshold is adjusted to the parameterized rated voltage
3)
Only the fundamental component
4)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
