Line Modules Booksize
4.8 Smart Line Modules with internal air cooling
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
291
Figure 4-81 Dimension drawing of 16 kW Smart Line Module with internal air cooling, all dimensions in mm and (inches)
Note
The shield c
onnecting plate is part of the scope of delivery of the 100 mm Smart Line
Modules.
