Line Modules Booksize
4.9 Smart Line Modules with external air cooling
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
325
Internal air cooling
6SL3131–
6AE15–0AAx
6AE21–0AAx
6TE21-6AAx
6TE23-6AAx
6TE25-5AAx
Rated power
kW
5
10
16
36
55
DC link currents
DC link output current
at DC 600 V
at DC 540 V
S6 (40 %)
at DC 600 V
Peak current
at DC 600 V
A
DC
A
DC
A
DC
A
DC
8,3
9,3
11
16,6
16,6
18,5
22
33,2
27
30
35
59
60
67
79
118
92
105
138
178
Current carrying capacity
DC link busbars
Reinforced DC link busbars
24 V DC busbars
A
DC
A
DC
A
DC
100
150
20
100
150
20
100
150
20
200
--
20
200
--
20
Electronics current drawn
at 24 V DC
A
DC
0,8
0,9
0,95
1,5
1,9
Total power loss
(incl. electronics losses)
internal
external
(see power loss tables
(Page 781))
W
W
W
79,2
41,2
38
141,6
66,6
75
187,8
64,8
123
406
116
290
665,6
185,6
480
Max. ambient temperature
without derating
with derating
° C
° C
40
55
DC link capacitance
Smart Line Module
Drive line-up, max.
μF
μF
220
6000
330
6000
705
20000
1410
20000
1880
20000
Power factor
cos ϕ
0.98
0.98
0.98
0.98
0.98
Circuit breaker
(IEC 60947 and UL)
See Section Overcurrent protection using line fuses and circuit breakers
(Page 51)
Rated short-circuit current
SCCR
3)
kA 65 65 65 65 65
Sound pressure level
dB(A)
< 60
< 60
< 60
< 65
< 60
Cooling air requirement
m
3
/h
29.6
29.6
56
112
160
Max. permissible heat sink
temperature
° C 69
4)
73
4)
77 80 75
Rated voltage for rated data 3 AC 380 V
Weight
kg
5.3
5.4
8.8
13.8
18.5
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
For 16 kW and 36 kW Smart Line Modules: Defaul
t for 400 V line supplies; undervoltage trip threshold is adjusted to the
parameterized rated voltage.
3)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
4
)
Values cannot be read out by the system (STARTER).
