Siemens 6SL3120-2TE21-0AA3

Line Modules Booksize
4.10 Smart Line Modules with cold plate
Booksize Power Units
Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
341
6SL3136-
6AE15-0AAx
6AE21-0AAx
Input currents
Rated input current
at AC 400 V
Input current
at AC 380 V / AC 480 V
at AC 400 V; S6 - 40 %
at AC 400 V; peak current
A
AC
A
AC
A
AC
A
AC
8,1
8,6 / 6,7
10,6
15,7
16,2
17 / 12,8
21,1
31,2
DC link currents
Rated DC link current
at 600 V
DC link current
at 540 V
at DC 600 V; S6 - 40 %
at DC 600 V; peak current
A
DC
A
DC
A
DC
A
DC
8.3
9.3
11
16.6
16.6
18.5
22
33.2
Current carrying capacity
DC link busbars
Reinforced DC link busbars
24 V DC busbars
A
DC
A
DC
A
DC
100
150
20
100
150
20
Electronics current drawn
at 24 V DC
A
DC
0.6
0.7
Power loss distribution
(incl. electronics losses)
internal
external
(see power loss tables (Page 781))
W
W
34.4
40
56.8
80
DC link capacitance
Smart Line Module
Drive line-up, max.
μF
μF
220
6000
330
6000
Power factor
cosϕ
1
1
Circuit breaker
(IEC 60947 and UL)
See Section Overcurrent protection using line fuses and
circuit breakers (Page 51)
Rated short-circuit current
SCCR
2)
kA 65 65
Max. permissible
heat-sink temperature
° C 60 65
Max. ambient temperature
without derating
with derating
° C
° C
40
55
40
55
Weight
kg
4,0
4,0
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
