Siemens 6SL3120-2TE21-0AA3

Line Modules Booksize Compact
5.1 Smart Line Modules Booksize Compact
Booksize Power Units
360 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
Smart Line Module Booksize Compact
6SL3430–
6TE21-6AAx
Rated power
kW
16
DC link currents
Rated DC link current
at 600 V
DC link current
at 540 V
at DC 600 V; S6 - 40 %
at DC 600 V; peak current
A
DC
A
DC
A
DC
A
DC
27
30
35
59
Current carrying capacity
DC link busbar
Reinforced DC link busbar:
24 V busbar:
A
DC
A
DC
A
DC
100
150
20
Electronics current consumption
at 24 V DC
For internal air cooling
For cold plate cooling
A
DC
A
DC
0.95
0.85
Total power loss internal air cooling
(including electronics losses, see Power loss
tables (Page 781))
W 187.8
Power loss distribution for cold plate
(including electronics losses)
3)
Internal
External
W
56.6
130
Max. ambient temperature
without derating
with derating
°C
°C
40
55
DC link capacitance
Smart Line Module
Drive line-up, max.
μF
μF
705
6000
Power factor
cos ϕ
0.98
Circuit breaker
(IEC 60947 and UL) See Chapter Overcurrent protection using line fuses
and circuit breakers (Page 51)
Rated short-circuit current SCCR
3)
kA
65
Cooling methods
Internal air cooling
Cold plate cooling
Cooling air requirement
with internal air cooling
m
3
/h
56
Max. permissible heat-sink temperature
cold plate
° C 71
Sound pressure level
dB(A)
< 60
Weight
kg 5.3
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
Default for 400 V line systems; undervoltage trip threshold is adjusted to the parameterized rated voltage
3)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
