Siemens 6SL3120-2TE21-0AA3

Motor Modules Booksize
6.3 Motor Module with external air cooling
Booksize Power Units
424 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
External air cooling
6SL3121–
1TE13-
0AAx
1)
1TE15-
0AAx
1)
1TE21–
0AAx
1)
1TE21–
8AAx
1)
1TE23-
0AAx
Max. ambient temperature
without derating
with derating
° C
° C
40
55
Sound pressure level
dB(A)
< 60
< 60
< 60
< 60
< 60
Cooling air requirement
m
3
/h
29,6
29,6
29,6
29,6
56
Max. permissible heat sink
temperature
° C 70 70 73 82 85
Weight
kg
5,7
5,7
5,7
5,7
8,4
1)
Applies only to order numbers with x = 0 .. 3
2)
Default for 400 V line systems; undervoltage trip threshold can be reduced by up to 80 V and is adjusted to the
parameterized rated voltage
3)
Rated power of a typical standard induction motor at 400 V 3 AC.
Table 6- 28 Technical data Single Motor Modules Booksize (45 to 200 A)
External air cooling
6SL3121–
1TE24-5AAx
1TE26-0AAx
1TE28-5AAx
1TE31-3AAx
1TE32-0AAx
Output current
Rated current (l
n
)
Base-load current (I
H
)
Intermittent duty current (I
s6
)
40%
Peak current (l
max
)
A
ACrms
A
A
ACrms
A
ACrms
45
38
60
85
60
51
80
113
85
68
110
141
132
105
150
210
200
141
230
282
Output voltage
V
ACrms
0 … 0.717 x DC-link voltage
DC-link current I
d max
A
DC
54 72 102 158 200
DC-link voltage
V
DC
510 … 720
DC-link capacitance
μF 1175 1410 1880 2820 3995
Overvoltage trip
Undervoltage trip
1)
V
DC
V
DC
820 ± 2 %
380 ± 2 %
Electronics power supply
V
DC
24 (20,4 - 28,8)
Electronics current drawn
at 24 VDC
A
DC
1,05
1,05
1,5
0,85
0,85
Current carrying capacity
DC-link busbars
24 VDC busbars
A
DC
A
DC
200
20
200
20
200
20
200
20
200
20
Unit rating
2)
Based on I
n
(600 VDC; 4 kHz)
Based on I
H
kW
kW
24
21
32
28
46
37
71
57
107
76
Total power loss
(including electronics losses,
see Power loss tables
(Page 781))
W 455,2 615,2 786 1270,4 2070,4
Max. pulse frequency
without derating
with derating
kHz
kHz
4
16
