UMSITRAPDS3-1 Model Designations and Specifications
November 2005
9-13
Other versions
Add "-Z" to order number and add short spec.
7MF4633 - . . . . . - . . . . -Z
Han 7D plug (metal, gray)
3)
A30
Han 8U plug (instead of Han 7D)
3)
A31
Sealing screw (1/4-18 NPT) with valve
in same material as process flanges
A40
Labeling of rating plate (instead of German):
- English
B11
- French
B12
- Spanish
B13
- Italian
B14
Manufacturer test certificate M acc. To DIN 55350, Part 18, and
ISO 8402
C11
Acceptance test certificate B acc. to DIN 50 049 / EN 10 204-3.1 B
C12
Works certificate acc. to DIN 50 049-2.2 / EN 10 204-2.2
C14
Setting the upper limit of the output signal to 22.0 mA
D05
IP 68 (not with Han 7D/Han 8U plug and cable screwed gland Pg 13.5)
D12
Application in zone 0 (basic device EEx ia)
3)
E02
Overfill protection for combustible and non-combustible liquids
(maximum PN 32 psi) (basic device EEx ia)
E08
Switching the process connection side
(HP side: left, LP side: right)
H01
Specify meas. range to be set in clear text,
Y01: ... to ... mbar, bar, kPa, Mpa, ... (27 characters maximum)
01
Specify tag number / description
(16 characters maximum) in clear text:
15
Specify tag message (27 characters maximum) in clear text:
16
Specify setting digital display in clear text: mbar, bar, kPa, MPa, ...
20
Factory presettings other than "Y01", "Y20" and "D05" are not possible.
Notes:
1)
Without cable screwed gland
2)
Not with "explosion proof” degree of protection
3)
Not FM approved
Scope of delivery:
Transmitter as ordered, 1 brief instruction (Leporello)
1 sealing screw (same material as process flange)
Order example:
Pos. 1 Position line: 7MF4633-1DY10-1AA1-Z
B-line: Y01
C-line: Y01: 1.3 to 2.1 inH
2
O
Pos. 2 Position line: 7MF4912-3DA11
