Siemens 7MF4233 series

Online Configuration Map for
Siemens SITRANS P DSIII Pressure Transmitter with
Model 375 Field Communicator
Notes:
1 Model 375 Field Communicator Firmware Rev. F1.6
2 Online 1 Pressure (PV) +
2 PV status 2 + = active data (measurement) display
3 Module type M = method (i.e. short procedure)
4 Identification 1 Operation Unit 1 Tag
2 Ext (Long) Tag --> M
3 Descriptor
4 Message
5 Date
2 Device 1 Manufacturer
2 Model
3 Device identification
4 Distributor
5 MLFB Order Number 1 MLFB Order No --> M
6 Measurement type
7 Fabrication-No
8 Final asembly number
9 Sensor serial number
10 Revisions 1 Universal rev.
2 Field device rev.
3 Software rev.
4 Hardware rev.
3 Basic Parameters 1 Pressure unit
2 LSL (Lower Sensor Limit)
3 USL (Upper Sensor Limit)
4 Minimum Span
5 LRV (Lower Range Value)
6 URV (Upper Range Value)
7 Pressure damping
8 Pressure xfer function xfer = transfer
5 Config Inp/Outp 1 Quick-Setup & Meas. 1 PV, Current, Status 1 PV +
2 AO (analogue output) +
3 PV % range +
4 Status see ---> 6 Diagnosis/Service
5 Measurement type
2 Meas.Val. & Status 1 Pressure Values 1 Pressure +
2 Pres status
3 Untrimmed pressure +
4 Untrimmed pres status
2 Temperature Values 1 Sens-Temp +
2 Sens-Temp status
3 Electr-Temp +
4 Electr-Temp status
3 Level, Vol, Mass Values 1 Level +
(shown if valid items) 2 Level status
3 Volume +
4 Volume status
5 Mass flow +
6 Mass status
4 Vol-, Mass- & Flow Values 1 Vol-Flow +
(shown if valid items) 2 Vol-Flow status
3 Mass-Flow +
4 Mass-Flow status
5 Appl & Stat 1 Customer Defined
(shown if valid items) 2 Customer Defined Status
3 Quick-Setup 1 Tag
2 Ext TAG --> M
3 PV is
4 PV unit
5 Position correction 1 Position corr --> M
6 LRV
7 URV
8 Pressure damping
9 Pressure xfer function
2 Input 1 Config Pres/Temp 1 Pressure sensor 1 Pressure +
2 Untrimmed pres +
3 Pressure units 1 Pres abs/rel
2 Pressure unit
3 Untrimmed pres unit
2 Temperature sensor 1 Sens-Temp +
2 Electr-Temp +
3 Temp units 1 Sens-Temp unit
2 Electr-Temp unit
3 Pres units see --> 1 Pressure sensor
4 Temp units see --> 1 Temperature sensor
Continued on pg 2 2 Display Process Variables 1 Process variables 1 PV measurement +
2 PV % range
3AO
4 S Temperature +
5 El Temperature +
6 Untrimmed pressure +
Page 1
