Siemens 7MF4233 series

Online Configuration Map for
Siemens SITRANS P DSIII Pressure Transmitter with
Model 375 Field Communicator
5 Config Inp/Outp, 2 Input, Continued 3 Meas Switch/Mapper 1 measurement
Continued 2 PV is
3 SV is
4 TV is
5 QV is
6 (measurement) config 1 Input scaling 1 Pres abs/rel
e.g. Level 2 Pressure unit
3 Input LRV
4 Input URV
2 Level scaling 1 Level unit
e.g. Level scaling 2 Level LRV
3 Level URV
3 Volume scaling 1 Volume unit
2 Vol LRV
3 Vol URV
2 Density unit
3 Density
3 Mass unit
6 (measurement) config 1 Input scaling 1 Pres abs/rel
e.g. Flow 2 Pressure unit
3 Input LRV
4 Input URV
2 Flow scaling 1 Vol flow unit
2 Vol flow LRV
3 Vol flow URV
2 Density unit
3 Density
3 Mass flow unit
6 (measurement) config 1 Input scaling 1 Pres abs/rel
e.g. Customer 2 Pressure unit
3 Input LRV
4 Input URV
3 Customer scaling 1 Cust unit (5 Ch)
2 Cust LRV
3 Cust URV
7 User linearization 1 Special Curve status --> only if meas not pres
if Level, Flow or Customer 2 No curve points
this is valid - otherwise not 3 Setup special char --> M
4 Display special char --> M
4 Meas.Limits & Span 1 Module range
2 Active Device Variables 1 Pressure 1 Pressure unit
2 Pres USL
3 Pres LSL
4 min span
5 Trimpoint sum
2 Sens-Temp 1 Sens-Temp unit
2 Sens-Temp USL
3 Sens-Temp LSL
4 Sens-Temp min.span
3 Electr-Temp 1 Electr-Temp unit
2 Electr-Temp USL
3 Electr-Temp LSL
4 Electr-Temp min.span
4 Untrimmed Pres 1 Untrimmed Pres unit
2 Untrimmed Pres USL
3 Untrimmed Pres LSL
4 Untr Pres min.span
additional if measurement 5 Level 1 Level unit
is mapped to level 2 Level USL
3 Level LSL
4 Level min.span
additional if measurement 6 Volume 1 Volume unit
is mapped to level 2 Volume USL
3 Volume LSL
4 Volume min.span
additional if measurement 7 Mass 1 Mass unit
is mapped to level 2 Mass USL
3 Mass LSL
4 Mass min.span
additional if measurement 5 Vol-Flow 1 Vol-Flow unit
is mapped to flow 2 Vol-Flow USL
3 Vol-Flow LSL
4 Vol-Flow min.span
additional if measurement 6 Mass-Flow 1 Mass-Flow unit
Continued on pg 3 is mapped to flow 2 Mass-Flow USL
3 Mass-Flow LSL
4 Mass-Flow min.span
additional if measurement 5 Customer 1 (PV) unit
is mapped to customer 2 Customer USL
3 Customer LSL
4 Customer min. span
Page 2
