System overview
1.7 HMI User Interface Software
Guide for the SINUMERIK 840D sl machine configuring
Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
1-11
Switching between embedded HMI and HMI-Advanced
When an Ethernet switch is used, you can switch between embedded HMI (available on
NCU) and HMI-Advanced (available on PCU 50.3).
(WKHUQHW
6ZLWFK
1&8 3&8
2SHUDWRU
3DQHO
PLW7&8
2SHUDWRU
3DQHO
PLW7&8
2SHUDWRU
3DQHO
PLW7&8
2SHUDWRU
3DQHO
PLW7&8
Figure 1-5 HMI-Advanced and embedded HMI on the Ethernet switch
Note
Detailed information about the operator panels, TCU and PCU 50.3 is contained in the "sl
Operator Components Device Manual" and in "CNC Commissioning, Part 2 (HMI)".
