NCU/NX Terminal Assignment
3.5 X122 and X132 Interface Overview
Guide for the SINUMERIK 840D sl machine configuring
3-6 Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
Occurring operator errors
Operator errors that frequently occur when starting macros include:
● incorrect status of p9
● active release to the modules
Note
If you have doubts, load the factory settings prior to executing a macro.
3.5 3.5 X122 and X132 Interface Overview
X122 and X132 interfaces for NCU 7x0
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
X132X122
'LJLWDOLQSXWV
SLQV
'LJLWDOLQSXWVRXWSXWVSLQV
DQG
Figure 3-2 X122 and X132 interfaces for NCU 7x0
Note
The NX1x component has only the X122 interface.
