Structure of the drive group
2.1 Structure
Guide for the SINUMERIK 840D sl machine configuring
2-4 Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
2.1.3 Two-row / multi-row construction
The components of the SINAMICS system can also be constructed as two or more rows. As
previously described above, the limit is the maximum DC link length and the current carrying
capacity of the DC link busbar. For the stacked construction, the appropriate ventilation
clearances must be observed in accordance with the Equipment Manual for Booksize Power
Units.
Note
Observe the installation and ventilation clearances; refer to the "Note for Connection Cable
Installation Clearance" section
3N:
3N:
0D[P
PP
PD[$
/LQH
9$&
/LQHILOWHU /LQHFKRNH
/LQH
0RGXOH
0RWRU
0RGXOHV
0RWRU
0RGXOHV
'&OLQN
DGDSWHU
&RROLQJ
FOHDUDQFH
Figure 2-3 Two-row construction
Note
For the layout of the NCU 7x0 or NX1x, see "Layout of the Components"
