2.6 Heat Dissipation of the Control Cabinet
Guide for the SINUMERIK 840D sl machine configuring
2-34 Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
Overview, power loss, external air cooling
Table 2-5 Overview of the power loss for components with external air cooling
Unit Internal
Power loss
External power loss Total power loss
Active Line Modules
16 kW W 60 200 260
36 kW W 135 495 630
55 kW W 200 700 900
80 kW W 305 1045 1350
120 kW W 490 1710 2200
Smart Line Modules
5 kW W 39 50 89
10 kW W 65 105 170
Single Motor Modules
3 A W 15 15 30
5 A W 23 30 53
9 A W 35 45 80
18 A W 75 90 165
30 A W 80 210 290
45 A W 110 320 430
60 A W 135 455 590
85 A W 160 590 750
132 A W 250 1000 1250
200 A W 435 1615 2050
Double Motor Modules
3 A W 35 35 70
5 A W 45 60 105
9 A W 65 95 160
18 A W 80 240 320
