NCU/NX Terminal Assignment
3.6 NCU 7x0 and NX1x Terminal Assignment
Guide for the SINUMERIK 840D sl machine configuring
Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
3-11
Pin
no.
Function Assignment recommendation BICO source/sink Macro number
Digital input $A_IN[4] CU: p2082[3]
4 Input
Line contactor, feedback signal
CU: r0722.7
LM : p0860 The macro does not
perform any BICO
interconnection; the
use of the function
requires
parameterization by
the user.
5 Ground for pins 1 ... 4
6 Ground for pins 7, 8, 10, 11
Infeed operation (Line Module with
DRIVE-CLiQ connection)
LM :r0863.0 1 7 Output
Digital output $A_OUT[4] CU: p2091.3
CU: p0742
5
Infeed ready to start (Line Module with
DRIVE-CLiQ connection)
LM : r0899.0 1 8 Output
Digital output $A_OUT[3] CU: p2091.2
CU: p0743
5
9 Ground for pins 7, 8, 10, 11
Digital output $A_OUT[2] CU: p2091.1 1/5 Output
Line contactor control LM : r0863.1
CU: p0744
The macro does not
perform any BICO
interconnection; the
use of the function
requires
parameterization by
the user.
Bero 2 – zero mark substitute CU: r 0722.14 Drive:
p0495 = 5
10
Input
2. OFF 2 Drive: p0845
The macro does not
perform any BICO
interconnection; the
use of the function
requires
parameterization by
the user.
Output Digital output $A_OUT[4] CU: p2091.0 CU: p0745 1/5
Probe 2 Central Measuring (check that
MD13210 = 0!)
CU: p0680[1] = 6 Each drive
p489 [1,2,3]=0
11
Input
Probe 2 - distributed measurement
(control MD13210 = 1)
CU: p0680[1] = 0 Each drive
p489 [1,2,3]=6
The macro does not
perform any BICO
interconnection; the
use of the function
requires
parameterization by
the user.
12 Ground for pins 7, 8, 10, 11
