Configuration using Web Based Management and Command Line Interface
4.4 The Agent menu
SCALANCE X-300 / X-400
Configuration Manual, 10/2014, C79000-G8976-C187-22
109
setec [event]
<E|D> <E|D>
<E|D> <E|D>
Specifies how an IE switch reacts to system events.
The following abbreviations are available for the event parameter:
• CW
Cold/Warm start
• LC
Link Change
• AF
Authentication Failure
• RA
RMON Alarm
• PC
Power Change
• RC
RM State Change
• SC
Standby State Change
• FC
Fault State Change
• RS
STP/RSTP Change
• LD
Loop Detection State Change
• PA
Port Auth State Change
• VE
VRRP State Change
(X414 only)
• FO
Fiber Optic Diagnostics
If an event is specified, the configured actions are formed for each
event.
The four parameters that follow <E> or <D> configure the reactions
of the IE switch in the order:
• E-mail
• Trap
• Entry in the log table
• Entry on the Syslog server
Example:
• setec LC E D D D
Only sends an E-mail if there is a Link Change.
Administrator
only.
