Siemens SCALANCE X-400 Configuration Manual

Configuration using Web Based Management and Command Line Interface
4.7 The Router menu (SCALANCE X414-3E)
SCALANCE X-300 / X-400
284 Configuration Manual, 10/2014, C79000-G8976-C187-22
Syntax of the Command Line Interface
Table 4- 90 Subnets - CLI\ROUTER\SUBNETS>
Command
Description
Comment
info
Displays the current subnets.
Administrator only.
add <VID> <IP> <subnet>
[name]
Adds a news subnet. The sub-
net parameter identifies the
subnet mask.
Administrator only.
edit <VID> <IP> [subnet] [name] Modifies a subnet. The subnet
parameter identifies the subnet
mask.
Administrator only.
delete <VID> <IP>
Deletes a subnet.
Administrator only.
The "info" CLI command displays a table (analogous to the table in the Web Interface). The
"Status" column is, however, restricted to two characters here (St).
The following statuses are possible (see also Web Interface):
● RI (RIP)
● OS (OSPF)
● st (static)
● ?? (invalid)
4.7.3
Current Routes
Routing table
The routing table is displayed in this dialog. Static routing table entries can also be created
here.
A routing table is generally a list of rules according to which received packets will be
forwarded. If a packet is waiting for routing, its destination address is compared with the
addresses in the routing table. The entry whose address along with the subnet mask
matches best (using the longest prefix match method) then describes how the packet will be
forwarded.
Entries in the routing table with the "local" status, indicate the configured subnets.
