Configuration using Web Based Management and Command Line Interface
4.5 The Switch menu
SCALANCE X-300 / X-400
Configuration Manual, 10/2014, C79000-G8976-C187-22
255
● Nominal Bit Rate (read only)
The nominal bit rate of the SFP port
● Max. Link (read only)
The maximum distance in meters that is possible with this medium.
The table is structured so that the latest (Current), the lowest (Low) and the highest (High)
value is always shown for the following parameters.
(read only)
The temperature of the port.
(read only)
The voltage applied to the port.
(read only)
The current with which a device connected to this port is supplied.
(read only)
The received power of the port.
(read only)
The transmit power of the port.
Syntax of the Command Line Interface
Table 4- 80 SFPDIAGNOSTIC - CLI\SWITCH\PORTDIAG\SFPDIAG>
Tests the specified SFP port.
