Configuration using Web Based Management and Command Line Interface
4.7 The Router menu (SCALANCE X414-3E)
SCALANCE X-300 / X-400
Configuration Manual, 10/2014, C79000-G8976-C187-22
319
This column shows the time at which the virtual router went into operation.
Note
The MIB object "vrrpOperVirtualRouterUpTime" represents the time at which the virtual
router was turned on. To make the
information clearer, the "Up Time" column shows how
long the virtual router has been turned on.
More precisely, the "Up Time" column shows the difference between the current sysUpTime
and the MIB object.
Shows how often this virtual router changed to the "Master" state.
Shows how often a packet was received that contained a bad address list.
This column shows the number of bad received packets whose advertisement interval no
longer matches the locally set value.
This column shows the number of bad received packets whose authentication type was not
type 0. Type 0 is the only acceptable type and means "no authentication".
Note
The "Auth Errors" column is the sum of the MIB objects "vrrpStatsInvalid
AthType" and
"vrrpStatsAuthTypeMismatch".
This column shows the number of bad received packets whose VRRP was not set correctly.
This column shows the number of bad received packets. This includes both packets with an
incorrect length as well as packets whose TTL value was incorrect in the IP header.
Note
The "Packet Errors" column is the sum of the MIB objects "vrrpStatsPacketLengthErrors"
and "vrrpStatsIpTtlErrors".
Displays how many packets with priority 0 were received. Packets with priority 0 are sent
when a master router is shut down. These packets allow a fast handover to the relevant
backup router.
Displays how many packets with priority 0 were sent. Packets with priority 0 are sent when a
master router is shut down. These packets allow a fast handover to the relevant backup
router.
