PROFINET IO functionality
6.4 Data record 0x802A (PDPortDataReal)
SCALANCE X-300 / X-400
348 Configuration Manual, 10/2014, C79000-G8976-C187-22
PeerChassisID
ID of the neighboring device.
LineDelay
LineDelay.FormatIndicator = 0
Value (hexadecimal)
Meaning
0x00000000
Line delay and cable delay unknown.
0x00000001 – 0x7FFFFFFF
Line delay in nanoseconds.
LineDelay.FormatIndicator = 1
Value (hexadecimal)
Meaning
0x00000000
Reserved
0x00000001 – 0x7FFFFFFF Cable delay in nanoseconds.
PeerMACAddress
MAC address of the neighboring device.
MAUType
Value (hexadecimal)
Meaning
0x0000 – 0x0004
Reserved
0x0005
10BASET
0x0006-0x0009
Reserved
0x000A
10BASETXHD
0x000B
10BASETXFD
0x000C
10BASEFLHD
0x000D
10BASEFLFD
0x000F
100BASETXHD
0x0010
100BASETXFD (default)
0x0011
100BASEFXHD
0x0012
100BASEFXFD
0x0013 – 0x0014
Reserved
0x0015
1000BASEXHD
0x0016
1000BASEXFD
0x0017
1000BASELXHD
0x0018
1000BASELXFD
0x0019
1000BASESXHD
0x001A
1000BASESXFD
0x001B – 0x001C Reserved
0x001D
1000BASETHD
