Page #350 background imageLoading...
Page #350 background image
PROFINET IO functionality
6.4 Data record 0x802A (PDPortDataReal)
SCALANCE X-300 / X-400
350 Configuration Manual, 10/2014, C79000-G8976-C187-22
LinkState.Port
Value (hexadecimal)
Meaning
0x00
Unknown
0x01
Disabled / discard
0x02
Blocked
0x03 Port listening enabled
0x04
Learn
0x05 Forward
0x06
Interrupted
0x07 – 0xFF
Reserved
MediaType
Value (hexadecimal)
Meaning
0x00
Unknown
0x01
Copper cable
0x02
Fiber-optic cable
0x00
Wireless communication
0x04 – 0xFFFFFFFF
Reserved
Note
You will find further information on the IEC data record in IEC 61158.
