Configuration using Web Based Management and Command Line Interface
4.3 The X-300/X-400 menu
SCALANCE X-300 / X-400
72 Configuration Manual, 10/2014, C79000-G8976-C187-22
Syntax of the Command Line Interface
Table 4- 16 X-300 Ring Configuration - CLI\X-300\RING>
X-400 Ring Configuration - CLI\X-400\RING>
info Displays the current ring configuration of the IE
-
red [mode] Enables/disables media redundancy in ring
topologies.
The following modes are possible:
• D
Disables media redundancy in ring topologies.
• HRP
The IE switch is an HRP client.
• HRPMGR
The IE switch is an HRP manager.
• MRPCL
The IE switch is an MRP client.
• MRP
The IE switch operates with MRP and can be-
come redundancy manager automatically.
• ARD
Automatic Redundancy Detection.
Administrator only.
ports [<port1> <port2>] Specifies the ring ports. Both ports must be speci-
Administrator only.
observer [D|R|P]
Specifies the observer function:
• D
Disables the observer function.
• R
Restarts the observer function.
• P
Enables the observer function.
Administrator only.
