Power Supply Modules
3-34
S7-400, M7-400 Programmable Controllers Module Specifications
A5E00069467-07
3.13 Power Supply Module PS 405 10A;
(6ES7405-0KA00-0AA0)
Function
The PS 405 10A power supply module is designed for connection to a DC line
voltage of 24 VDC and supplies 5 VDC/10 A and 24 VDC/1 A on the secondary
side.
Controls and Indicators of the PS 405 10 A
LEDs INTF,
BAF, BATT1F, BATT2F,
5 VDC, 24 VDC
FMR pushbutton (Failure Message Reset)
Standby switch
Switches BATT. INDIC.
2 BATT, OFF, 1 BATT
Battery compartment
Fixing screw
3-pin plug-in power connector
PS 405 10 A
405-0KA00-0AA0
X2
34
1
FMR
2
INTF
BAF
BATTF
5 VDC
24 VDC
BATTF
BATT. INDIC.
2 BATT
1 BATT
OFF
BATT.1 BATT.2
+
+
Under cover
Fixing screw
Figure 3-9 Controls and Indicators of the PS 405 10 A
