S7-400, M7-400 Programmable Controllers Module Specifications
A5E00069467-07
Table 4-2 Digital Output Modules: Characteristics at a Glance
Module
Characte-
ristics
SM 422;
DO 16 24
VDC/2 A
(-1BH1x)
SM 422;
DO
16 20-125
VDC/1.5 A
(-5EH10)
SM 422;
DO
32 24
VDC/ 0.5 A
(-1BL00)
SM 422;
DO 32 24
VDC/0.5 A
(-7BL00)
SM 422;
DO
8 120/230
VAC/5 A
(-1FF00)
SM 422; DO
16 120/230
VAC/2 A
(-1FH00)
SM 422;
DO
16 20-120
VAC/2 A
(-5EH00)
Number of
outputs
16 DO;
isolated in
groups of 8
16 DO;
isolated
and reverse
polarity
protection
in groups of
8
32 DO;
isolated in
groups of
32
32 DO;
isolated in
groups of 8
8 DO;
isolated in
groups of 1
16 DO;
isolated in
groups of 4
16 DO;
isolated in
groups of 1
Output current 2 A 1.5 A 0.5 A 0.5 A 5 A 2 A 2 A
Rated load
voltage
24 VDC 20 to 125
VDC
24 VDC 24 VDC 120/
230 VAC
120/
230 VAC
20 to
120 VAC
Programmable
diagnostics
No Yes No Yes No No Yes
Diagnostic
Interrupt
No Yes No Yes No No Yes
Substitute
value output
No Yes No Yes No No Yes
Special
Features
For high
currents
For variable
voltages
High
packaging
density
Particularly
quick and
with
interrupt
capability
For high
currents
with
channel-
specific
isolation
– For variable
currents
with
channel-
specific
isolation
Table 4-3 Relay Output Module: Characteristics at a Glance
Module
Characteristics
SM 422; DO 16 30/230 VUC/Rel. 5 A
(-1HH00)
Number of Outputs 16 outputs, isolated in groups of 8
Load Voltage 125 VDC
230 VAC
Special Features –
