Interface Submodules
13-4
S7-400, M7-400 Programmable Controllers Module Specifications
A5E00069467-07
13.2 Submodule IDs and Insertion Rules
Submodule IDs
The following table contains an overview of the submodule IDs for the interface
submodules.
Table 13-2 Overview of the Submodule IDs for the Interface Submodules
Interface Submodule
Submodule ID
IF 961-AIO 01
H
IF 961-CT1 03
H
IF 961-DIO 02
H
IF 962-COM 41
H
IF 962-LPT 44
H
IF 962-VGA 81
H
IF 964-DP 8C
H
Insertion Rules
The interface submodules cannot be operated in all submodule receptacles. The
following table shows the insertion rules for those interface submodules that cannot
be used in all receptacles:
Table 13-3 Insertion Rules for Interface Submodules that Cannot be Used in All Receptacles
Submodule Receptacle Numbers in the Following Modules
Interface Submodule
EXM 378-2 EXM 378-3 FM 456-4
CPU 486-3/
CPU 488-3
EXM 478
1 2 3 4 5 0 1 0 3 all
IF 962-VGA
6ES7 962-1BA00-0AC0
  –       
IF 964-DP
6ES7 964-2AA00-0AB0
  –      
*)

*)
Preferred slot for IF 964-DP if only one submodule is inserted, see Table 11-8 on page 11-40.
