Digital Modules
4-75
S7-400, M7-400 Programmable Controllers Module Specifications
A5E00069467-07
Technical Specifications of the SM 422; DO 32 24 VDC/0.5 A
Dimensions and Weight
Dimensions W H D
(in millimeters)
25 290 210
Weight Approx. 600 g
Data for Specific Module
Number of outputs 32
Length of cable
Unshielded
Shielded
600 m
1000 m
Voltages, Currents, Potentials
Power rated voltage of the
electronics L+
24 VDC
Rated load voltage L+ 24 VDC
Total current of the outputs (per
group)
Up to 40 C
Up to 60 C
Max. 4 A
Max. 2 A
Isolation
Between channels and
backplane bus
Yes
Between the channels
In groups of
Yes
8
Permitted potential difference
Between the different
circuits
75 VDC, 60 VAC
Insulation tested with
Channels against
backplane bus and load
voltage L+
500 VDC
Between the outputs of the
different groups
500 VDC
Current consumption
From the backplane bus
Power supply and load
voltage L+ (no load)
Max. 200 mA
Max. 120 mA
Power dissipation of the
module
Typ. 8 W
Status, Interrupts, Diagnostics
Status display Green LED per
channel
Interrupts
Diagnostic Interrupt
Hardware interrupt
Parameters can be
assigned
Parameters can be
assigned
Diagnostic functions
Monitoring of the load
voltage
Yes
Group error display
For internal fault Red LED (INTF)
For external fault Red LED (EXTF)
Diagnostic information
readable
Yes
Monitoring for
Short circuit > 1 A (typ.)
Wire break < 0.15 mA
Substitute value can be applied Yes
Data for Selecting an Actuator
Output voltage
At signal “1” Min. L + (– 0.8 V)
Output current
At signal “1”
Rated value
Permitted range
0.5 A
5 mA to 0.6 A
At signal “0” (leakage
current)
Max. 0.5 mA
Load resistor range 48 to 4 k
Parallel connection of 2
outputs
For redundant triggering of
a load
Possible (only outputs
of the same group)
To increase performance Possible (only outputs
of the same group)
Triggering a digital input Possible
Switch rate
For resistive load Max. 100 Hz
For inductive load
to IEC 947-5-1, DC 13
Max. 2 Hz
For lamp load Max. 2 Hz
Limit (internal) of the inductive
circuit interruption voltage up to
Typ. L + (– 45 V)
Short-circuit protection of the
output
Threshold on
Electronically cyclic
Typ. 0.75 A to 1.5 A
