Interface Submodules
13-60
S7-400, M7-400 Programmable Controllers Module Specifications
A5E00069467-07
13.8.3 Technical Specifications
Technical Specifications
The IF 961-CT1 interface submodule receives its supply voltage from the M7-400
programmable modules or from the M7-300/400 expansion modules. The current
consumption given in the technical specifications is the consumption required for
dimensioning the power supply, that is, the current consumption is referenced to
24 V in the M7-300 and to 5 V in the M7-400.
6ES7961-3AA00-0AC0
Technical Specifications
Supply voltage Supplied from the
M7-400
programmable
modules or from the
M7-300/400
expansion modules
Current consumption in the
M7-300
(for dimensioning the 24 V
current supply)
0.053 A
Current consumption in the
M7-400
(for dimensioning the 5 V
current supply)
0.15 A
Nominal voltage load
current supply
2L+ / 2M
24 VDC
Current consumption
2L+ / 2M
Depends on the
load of the digital
outputs
Type ID 03
H
Power losses 1.5 W
Dimensions
W x H x D (mm)
18.2 x 67 x 97
Weight 0.07 kg
Counter Inputs 5 V
Number of counter
channels
1, alternative to 24 V
Level In accordance to
RS422
Terminating resistance approx. 220 ohms
Differential voltage min 0.5 V
Sensor voltage No
Sensor monitoring Yes
Counter range 32 bits
Max. counter frequency 500 kHz
Counter Inputs 24 V
Number of counter
channels
1, alternative to 5 V
Low level
High level
- 30 V to + 5 V
+ 11 V to + 30 V
Input resistance
1 k
Input current typ. 7 mA
Sensor voltage No
Sensor monitoring No
Counter range 32 bits
Max. counter frequency 200 kHz
Digital Inputs
Supply voltage 2L+ / 2M
Number of inputs 4
Low level
High level
- 30 V to + 5 V
+ 11 V to + 30 V
Input current typ. 7 mA
Galvanic isolation Yes, to all others
except the digital
outputs
Input filter
(can be set)
50 kHz, 200 kHz
Digital Outputs
Supply voltage 2L+ / 2M
Number of outputs 2
Galvanic isolation Yes, to all others
except the digital
inputs
Output voltage
– Low level
– High level
max. 3 V
2 L+ - 1.5 V
Switching current
– Nominal value
– Range
0.3 A
5 mA to 0.3 A
Switching time max. 300 ms
Cutoff voltage (inductive) Limited to
2L+ + (39 V
Short-circuit protection Yes, via electronic
fuse
