Configuring with Web Based Management
6.4 "Information" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
170 Configuration Manual, 08/2018, C79000-G8976-C267-13
The WBM page shows how many frames in response to logging on or logging off were
counted per VAP interface.
is only available in access point mode.
The table has the following columns:
●
Shows the VAP interface to which the entries apply.
●
– Management Frames
Shows the number of management frames
– Association Requests
Shows the number of requesting association frames relevant for a logon.
– Association Responses
Shows the number of responding association frames relevant for a logon.
– Disassociation Requests
Shows the number of requesting disassociation frames relevant for a logoff.
– Authentication Requests
Shows the number of requesting authentication frames relevant for a logon.
– Authentication Responses
Shows the number of responding authentication frames relevant for a logon.
– Deauthentication Requests
Shows the number of deauthentication frames relevant for a logoff.
