Page #316 background imageLoading...
Page #316 background image
Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
316 Configuration Manual, 08/2018, C79000-G8976-C267-13
6.6.2.13
Spectrum analyzer
Technical information
The frequency range depends on the configuration.
Parameters
Value
Amplitude accuracy
In 2.4 GHz
3 dBm
In 5 GHz
7 dBm
Resolution bandwidth
330 KHz
Min. signal strength
-100 dBm
Max. signal strength
0 dBm
Analysis time At 40 MHz 120 ms
At 20 MHz
95 ms
Update time
1 s.
