Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
285
3. Select the relevant check box for the required channel number.
4. Click the "Set Values" button.
802.11n
Properties of 802.11n
With the IEEE 802.11n standard, it is possible to put together individual data packets in one
larger data packet, the A-MPDU and A-MSDU data packets. This achieves a higher data
throughput.
On this page, you make the settings for the A-MPDU and A-MSDU data packets. Some of
the settings depend on the set transmission standard and the selected channel width.
The table has the following columns:
●
Shows the available WLAN interfaces.
●
Aggregated MAC Protocol Data Unit (A-MPDU)
Enables or disables that several MPDUs with the same destination address are sent as a
large A-MPDU. This allows the total throughput to be increased.
If this check box is disabled, A-MPDU data packets are received but not sent.
●
Specify the number of individual data packets grouped together in one A-MPDU data
packet.
Range of values: 2 - 64 frames
●
Specify the maximum size of the A-MPDU data packet.
Range of values: 1024 - 65535 bytes
Default: 50000 bytes
