Upkeep and maintenance
7.2 Device configuration with PRESET-PLUG
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
423
Device configuration with PRESET-PLUG
Please not the additional information and security notes in the operating instructions of your
device.
Do not remove or insert a PLUG during operation
A PLUG may only be removed or inserted when the device is turned off.
Note
Support as of V6.0
The PRESET
-PLUG functionality is supported as of firmware version V6.0.
With the PRESET-PLUG, you can install the same device configuration (start configuration,
user accounts, certificates) including the corresponding firmware on multiple devices.
The PRESET PLUG is write-protected.
You configure the PRESET PLUG using the Command Line Interface (CLI).
You create the PRESET PLUG using the Command Line Interface (CLI). You can create a
PRESET-PLUG from any PLUG. To do this, follow the steps outlined below:
Note
Using configurations with DHCP
Create a PRESET
-PLUG only from device configurations that use DHCP. Otherwise
disruptions will occur in network operation due to multiple identical IP addresses.
You assign fixed IP addresses extra following the basic ins
tallation.
● A PLUG is inserted in the device on which you want to configure the PRESET-PLUG
functionality.
1. Start the remote configuration using Telnet (CLI) and log on with a user with the "admin"
role.
2. Change to the Global configuration mode with the command "configure terminal".
3. You change to the PLUG configuration mode with the "plug" command.
4. Create the PRESET-PLUG with the "presetplug" command.
The firmware version of the device and the current device configuration incl. user
accounts and certificates are stored on the PLUG and the PLUG is then write protected.
5. Turn off the power to the device.
