Configuring with Web Based Management
6.9 "Security" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
360 Configuration Manual, 08/2018, C79000-G8976-C267-13
On this page you link a group with a role.
In this example the group "Administrators" is linked to the "admin" role: The group is defined
on a RADIUS server. The role is defined locally on the device. When a RADIUS server
authenticates a user and assigns the user to the "Administrators" group, this user is given
rights of the "admin" role.
Note
The values displayed depend on the rights of the logged
-in user.
The page contains the following:
●
Enter the name of the group. The name must match the group on the RADIUS server.
The name must meet the following conditions:
– It must be unique.
– It must be between 1 and 64 characters long.
The table contains the following columns:
●
Select the check box in the row to be deleted.
●
Shows the name of the group.
