Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
315
● CL / AP RX-Signal [dBm]
The effective user data signal of the client (CL) / access point (AP) in dBm
● CL / AP NF [dBm]
The background noise in dBm
● CL / AP RSSI
The raw value of the RSSI (Received Signal Strength Indication)
● Roam
The roaming counter shows how often the client has changed access points during the
recording. After 4 294 967 295 changes the counter is reset.
● CL / AP Retry
The transfer repetitions of the client (CL) / access point (AP)
● Con Stations
Number of clients connected to the access point.
● Operating Ch.
The current channel or the channel on which the client is connected to the access point
● HT-40
The channel bandwidth 40 MHz
● Scan CH
The channel on which the client is currently scanning.
● TX-Rate
The average data rate of the sent data packets
● RX-Rate
The average data rate of the received data packets
Note
The columns that relate to the management channel only contain a value if there is an iPCF
-
● M-Ch
The management channel
● M-Sig
The effective user data signal of the management channel
● M-NF
The background noise of the management channel
● AP System Name
The system name of the access point
