6.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
322 Configuration Manual, 08/2018, C79000-G8976-C267-13
● Color Scheme
With this icon, you change the color scheme for the graphic type "Spectrogram":
– The color goes from the lowest value (-100 dBm) in black to the highest value (0 dBm)
in red.
– The color goes from the lowest value (-100 dBm) in red to the highest value (0 dBm) in
black.
● Reset
With this icon you reset the maximum and average values of the graphic type "Realtime".
This table contains the following columns:
●
Radio
Shows the WLAN interface to which the information applies.
●
State
Shows the status of the measurement. The following values are possible:
– stopped
The measurement was stopped.
– running
The measurement is running.
●
Frequency Band
Specify the frequency band.
●
Center Frequency
Select the center frequency.
●
Start
Click the button in this column to start the measurement.
●
Stop
Click the button in this column to end the measurement.
Procedure
1. Select the required frequency band from the "Frequency Band" drop-down list.
2. Select the required center frequency from the "Center Frequency" drop-down list.
3. Click the "Start" button.
4. To stop the measurement, click the "Stop" button.
5. You can adapt the settings in the second table during the measurement.
