Siemens SIMATIC NET SCALANCE W700 User Manual

Configuring with Web Based Management
6.7 "Layer 2" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
341
this port. When the connection is established the first time, the port is treated as a "no
Edge Port".
– Admin/Auto
Select these options if you operate a combination of both on this port. When the
connection is established the first time, the port is treated as an Edge Port.
●
Edge
Shows the status of the port.
– Enabled
An end device is connected to this port.
– Disabled
There is a spanning tree or rapid spanning tree device at this port.
With an end device, a switch can change over the port faster without taking into account
spanning tree frames. If a spanning tree frame is received despite this setting, the port
automatically changes to the "Disabled" setting for switches.
●
P.t.P. type
Select the required option from the drop-down list. The selection depends on the port that
is set.
– P.t.P.
Even with half duplex, a point-to-point link is assumed.
– Shared Media
Even with a full duplex connection, a point-to-point link is not assumed.
Note
Point
-to-point link means a direct connection between two devices. A shared media
connection is, for example, a connection to
a hub.
– "-"
Point to point is determined automatically. If the port is set to half duplex, a point-to-
point link is not assumed.
●
P.t.P.
– Enabled
Shows that a point-to-point link exists.
– Disabled
Shows that no point-to-point link exists
●
Hello Time
Enter the interval after which the bridge sends configuration BPDUs. As default, 2
seconds is set.
Range of values: 1-2 seconds
Note
The port
-specific setting of the Hello time is only possible in MSTP compatible mode.
