Siemens SIMATIC PCS 7 Service Manual

Diagnostics for Diagnostics tool Called via
Internal PROFIBUS DP interface of the
CPU
Module Information (Page 131) Diagnostics via HW Config > Module Information
PROFIBUS DP error PROFIBUS DP Diagnostics
With Diagnostic Repeater
(Page 132)
Diagnostics via HW Config > Module Information
Status of PROFIBUS nodes NetPro (Page 115) In the Start menu, Siemens SIMATIC programs:
STEP 7 > NetPro
Select the menu command View > With DP
Slaves to display the DP slaves in the network
view
Status of stations NCM S7 (Page 118) In the Start menu, Siemens SIMATIC programs:
STEP 7 > NCM S7 > Diagnostics
8.10 Diagnostics on PROFINET
Overview
Diagnostics for Diagnostics tool Called via
Devices and connections with diagnos‐
tic capability
Maintenance Station (Page 90) The Maintenance Station is an operator station
that is specially configured for use in diagnostics.
The Maintenance Station has to be configured.
Additional information is available in the docu‐
mentation Process Control System PCS 7; Main‐
tenance Station
Determining inventory data of field devi‐
ces
SIMATIC Management Con‐
sole (Page 62)
In the Start menu, Siemens SIMATIC programs:
SIMATIC > SIMATIC Management Console (Li‐
cense required)
Plant view > Shortcut menu command "Deter‐
mine inventory data"
Additional information is available in the online
help for SIMATIC Management Console .
Internal PROFINET interface of the CPU
(only for CPU 41x- PNIO
Module Information (Page 131) Diagnostics via HW Config > Module Information
Status of PROFINET stations Topology Editor (Page 118) Diagnostics via Edit > PROFINET IO > Topolo‐
gy.
Status of PROFINET stations NetPro (Page 115) In the Start menu, Siemens SIMATIC programs:
STEP 7 > NetPro
Select the menu command View > With DP
Slaves to display the DP slaves in the network
view
Status of stations NCM S7 (Page 118) In the Start menu, Siemens SIMATIC programs:
STEP 7 > NCM S7 > Diagnostics
Diagnostics in PCS 7
8.10 Diagnostics on PROFINET
Service Support and Diagnostics (V8.2)
100 Service Manual, 03/2016, A5E36200111-AA
