Information on Detailed information Called via Additional information
Faults on PRO‐
FIBUS
Only when a diagnostic repeat‐
er is used
PLC > PROFIBUS >
Display Network Topol‐
ogy
Status of DP
slaves
Display DP slaves in the net‐
work view
View > With DP Slaves
8.18.3.2 NCM S7 Industrial Ethernet
Call
In the Siemens SIMATIC programs Start menu: STEP 7 > NCM S7 Industrial Ethernet >
Diagnostics
Overview
Information on Detailed information Called via Additional information
CP status Dynamic information about
the operating mode of the
communication functions of
CPs connected online
Diagnostics > Online >
Open Connection
Online help for STEP 7 ,
topic: "Hardware diagnos‐
tics"
Manual SIMATIC NET;
NCM S7 for Industrial
Ethernet
General CP diag‐
nostics and statis‐
tics functions
Operating mode
Scan event messages recor‐
ded in the Ethernet CP
Diagnostics > Online >
Open Connection
Diagnostics func‐
tions depending
on CP type and
operating mode
ISO transport connections
ISO-on-TCP connections
TCP connections
UDP connections
E-mail connections
Diagnostics > Online >
Open Connection
8.18.3.3 SCALANCE X-300/X-400 “Observer function”
Call
Called via Web Based Management or TELNET
Diagnostics in PCS 7
8.18 Diagnostic tools
Service Support and Diagnostics (V8.2)
116 Service Manual, 03/2016, A5E36200111-AA
