Information on Detailed information Called via Additional information
Time master for
OS server (sta‐
tus)
Status information
● Active master
● Standby master
● Slave
● Deactivated
Process picture on the OS
● Configured text tags on
the faceplate
You can find information on
configuration in the online
help of the WinCC Informa‐
tion System
8.18.5 Diagnostics for the BATCH station
8.18.5.1 Status icons in the BATCH server taskbar
Overview
Information on Detailed information Called via Additional information
Status server BATCH Launch Coordinator in the BATCH server
taskbar
You can open the
BATCH Launch Coordi‐
nator from the shortcut
menu.
Online help for SIMATIC
BATCH
Status of redun‐
dant servers
Monitoring a BATCH Launch Coordinator from a BATCH client
You can monitor the status of any Batch plant by running the BATCH Launch Coordinator on
a BATCH client without BATCH server installation. A dialog with all the loaded Batch plants
opens for this purpose when the Launch Coordinator starts. After selecting a Batch plant, the
symbol of the Launch Coordinator appears with the plant status in the status bar of the BATCH
client.
Status symbols of the BATCH Launch Coordinator
The symbol includes a status display for SIMATIC BATCH. The possible states are listed in
the table below.
Symbol Meaning
Without status symbol. No connection to the BATCH project. The BATCH project is not loaded and
SIMATIC BATCH is waiting for BATCH data. Or BATCH data has been loaded, but the server
applications have not yet started.
SIMATIC BATCH is ready (Ready). The BATCH project is loaded and started.
Intermediate state. A status change is in progress (Processing).
Intermediate state. Preparing to transition to the "Running" state (Running Prepared).
Diagnostics in PCS 7
8.18 Diagnostic tools
Service Support and Diagnostics (V8.2)
126 Service Manual, 03/2016, A5E36200111-AA
