Siemens SIMATIC PCS 7 Service Manual

Overview
Information on Detailed information Called via Additional information
Status redundancy
manager
The observer function
provides
error diagnostics and
error protection for ring
structures (ring redun‐
dancy in plant bus/termi‐
nal bus)
Enter the following in
the "Run" dialog of the
Start menu: "cmd"
In the DOS window,
enter TELNET . Addi‐
tional information in the
documentation SIMAT‐
IC NET; Industrial
Ethernet SwitchesSCA‐
LANCE X‑300 / X‑400
Documentation SIMAT‐
IC NET; Industrial Ether‐
net Switches
SCALANCE X‑300 /
X‑400
8.18.3.4 SCALANCE XB-200/X-200/X-300/X-400 “Loop detection”
Calling
Called via Web Based Management.
Overview
Information on Detailed information Called via Additional information
Loop detection The "Loop detection" function
allows you to specify the
ports for which loop detection
should be enabled.
Web Based Management "Industrial Ethernet switches
SCALANCE X-200" Configu‐
ration Manual
"Industrial Ethernet Switches
SCALANCE X-300 / X-400"
Configuration Manual
"Industrial Ethernet switches
SCALANCE XB-200" Web
Based Management
8.18.3.5 "Network Connections" Windows dialog box
Overview
Information on Detailed information Called via Additional information
Status of network
cards on Industri‐
al Ethernet
Dynamic display of the status
of physical and virtual net‐
work adapters
In the Start menu via the
Network Connections
Online help of the oper‐
ating system
Diagnostics in PCS 7
8.18 Diagnostic tools
Service Support and Diagnostics (V8.2)
Service Manual, 03/2016, A5E36200111-AA 117
