Diagnostics for Diagnostics tool Called via
Connection error Module Information (Page 131) Select the SIMATIC station in SIMATIC Manag‐
er or
the CPU in HW Config.
Open signal interconnections in PCS 7
Operator Station
PCS 7 operator station
(WinCC)
Convert pictures
Connection functions for a PC station Set PC Station (Page 112) In the Start menu, Siemens SIMATIC programs:
SIMATIC NET > Settings > Set PC Station
8.7 Diagnostics for the CPU
Overview
Diagnostics for Diagnostics tool Called via
CPU module information, redundancy,
connections
Maintenance Station (Page 90) The Maintenance Station is an operator station
that is specially configured for use in diagnostics.
The Maintenance Station has to be configured.
Additional information is available in the manual
Process Control System PCS 7; Maintenance
Station
Determining inventory data of automa‐
tion systems
SIMATIC Management Con‐
sole (Page 62)
In the Start menu, Siemens SIMATIC programs:
SIMATIC > SIMATIC Management Console (Li‐
cense required)
Plant view > Shortcut menu command "Deter‐
mine inventory data"
Additional information is available in the online
help for SIMATIC Management Console .
CPU HW Config (Page 130) Select CPU: Menu command
Station > Online
CPU Module Information (Page 131) Select the SIMATIC station in SIMATIC Manag‐
er or
Select the CPU in HW Config.
Select the menu command PLC > Module Infor‐
mation
Module displays Evaluating the Module Display
(Page 104)
Notes on the manuals: Diagnostics for hardware
displays (Page 104)
CPU fault - preparing diagnostics Only to support experts CPU fault - preparing diagnostics (Page 83)
Diagnostics in PCS 7
8.7 Diagnostics for the CPU
Service Support and Diagnostics (V8.2)
98 Service Manual, 03/2016, A5E36200111-AA
