Components You can find information about diagnostic options in the following manuals and
sections:
DP/PA Coupler Operating instructions
DP/PA couplers, active field distributor, DP/PA Link and
Y Link
Diagnostics by means of LED displays
LED displays of the IM 157
LED displays of the DP/PA coupler
LED displays of the Y coupler
Y-Link Information under DP/PA Coupler
FF Link Operating instructions
SIMATIC; FF Link
bus link
Compact FF Link Operating instructions
SIMATIC; Compact FF Link
bus link
AFD
(use on fieldbus -
PROFIBUS PA or
FOUNDATION Field‐
bus)
Manual
SIMATIC;
SIMATIC NET; PROFIBUS PA
Diagnostics by means of LED displays
Diagnostic messages for electronic modules
AFDiS Operating instructions
DP/PA couplers, active field distributor, DP/PA Link and
Y Link
LED displays of the AFDiS active field distributor
AFDiSD
(Use on fieldbus -
PROFIBUS PA)
Operating instructions
DP/PA coupler, active field distributor, DP/PA Link and
Y Link
Product information
SIMATIC; Bus Link;
Supplements to the operating instructions FF Link 03/2015
Operating instructions
SIMATIC; Bus Link;
Extended fieldbus diagnostics in PROFIBUS PA
LED displays of the field distributor
AFS (use on fieldbus -
PROFIBUS PA or
FOUNDATION Field‐
bus)
Manual
SIMATIC;
SIMATIC NET; PROFIBUS PA
Diagnostics by means of LED displays
Diagnostic messages for electronic modules
Diagnostic repeaters Manual
SIMATIC;
Diagnostic Repeater for PROFIBUS DP
LED diagnostics
Switch for Ethernet Operating instructions
SIMATIC NET;
Industrial Ethernet Switches SCALANCE X-400
LED
Commissioning manual
SIMATIC NET; Industrial Ethernet, SCALANCE X-100
and SCALANCE X-200 Product Line
SCALANCE X<…> displays (SCALANCE X208 displays, for example)
Status LEDs for PROFINET IO and PROFIBUS DP
Comparison of LEDs for diagnostics
Diagnostics in PCS 7
8.17 Diagnostics for hardware displays
Service Support and Diagnostics (V8.2)
106 Service Manual, 03/2016, A5E36200111-AA
